Combination Type Metal Oxide Surge Arrester 6kV For Shunt Compensation

Ask Lasest Price
Brand Name :	Xi'an Shendian
Model Number :	YH5WR1-10/27×10/27
Certification :	IEC 60099-4/ GB 11032
Price :	To be determined by type and quantity.
Payment Terms :	T/T; L/C.
Supply Ability :	0.5M pc/year.
Delivery Time :	Ex-work 1 week~1 month depends on quantity.

Add to Cart

Product Details
Company Profile

Combination Type Metal Oxide Surge Arrester 6kV For Shunt Compensation

6kV Combination Type 3P Surge Arrester For Shunt Compensation

Product introduction:

Combined polymer metal-oxie surge arrester has been widely used for interphase protection and phase protection in the industry of petrochemical, railway and coal industry, etc.

Work Condition:

1/ Indoor;

2/ -40℃+40℃;

3/ Altitude up to 2600m;

4/ Power supply frequency range from 48Hz to 62Hz;

5/ Anti-seismic: 0.25g;

Standard Technical Data:

Below info. only for your reference, all data shall be specified and determined by technical specification and customer demand.

Item	Description		Offered
1	Manufacture/ Country of Origin		Xi'an Shendian/ China
2	Model		YH5WR1-10/27×10/27
3	Applicable standard		IEC 60099-4
4	Type		Outdoor, ZnO, gapless
5	Norminal voltage of system	kV	6
6	Earthing system		Effectively earthed
7	Rated frequency	Hz	50/60
8	Rated voltage of SA	kV	10
9	Maximum continuous operating voltage	kV	8
10	Connection mode		Phase-Phase/ Phase-Earth
11	Power frequency reference voltage	kV	15.0/14.4
12	at reference current of	mA (D.C)	1
12	Note: State peak value or rms.	mA (D.C)	1
13	Nominal discharge current	kA	5
14	(a) Lightning impulse	kV	≤27/27
	(b) Steeping impulse	kV	/
	(c) Switching impulse	kV	≤23/23

Schematic diagram:

Reference:

1/ Shendian MOA is widely used in China EHV (Extra hight voltage) projects of State Grid, Southern Power Grid.

2/ Supplied MOA to ABB/Siemens/Schneider more than 20 years, as well as other capacitor/switchgear manufacturers.

3/ Shendian MOA has been exported to more than 30 counties all over the world.
