110kV Neutral Grounding Equipment with Surge Arrester Plus Switch and CT

Product Categories

Shendian Electric Co. Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Ask Lasest Price
Brand Name :	Xi'an Shendian
Model Number :	TJZB-35
Certification :	IEC 60099-4/ GB 11032
Price :	To be determined by type and quantity.
Payment Terms :	T/T; L/C.
Supply Ability :	1000 pc/year.
Delivery Time :	Ex-work 30 days~60 days depends on quantity.

Add to Cart

35kV Neutral Grounding Protection Device for Transformer

Product introduction:

This kind of transformer neutral protection device adopts modular construction.

It has been running well in high altitude area over decades year.

Characteristic:

1/ Entirety assembly and transportation;

2/ Easy to install and more stable;

3/ Anti-corrosion and anti-aging.

Standard Technical Data:

Below info. only for your reference, all data shall be specified and determined by technical specification and customer demand.

Item	Description			Offered
1	Type			TJZB-35
2	TR rated voltage		kV	35
3	Power frequency voltage		kV	95
4	Lightning impulse voltage withstand		kV	185
5	Metal-oxide surge arrester	Type		Y(H)1.5W-30/98
		Rated voltage	kV	30
		Residual voltage at lightning impulse	kV	≯98
		Residual voltage at switching impulse	kV	≯88
		Reference voltage at D.C. 1mA	kV	≮61
		Leakage current at 0.75U1mA	μA	≯50
6	Disconnect switch	Rated voltage	kV	40.5
		Rated current	A	630
		Operation mechanism		Motor/ Manual
		Rated short-time current withstand	kA	31.5
		Rated peak current withstand	kV	80
7	Current transformer	Rated voltage	kV	10
		Rated insulation level		42/75
		Rated dynamic current	kA	110
8	Discharge gap	Gap type		Ball/ Rod
		Power frequecny discharge voltage	kV	55±10%
		Impulse discharge voltage	kV	≯150
		Gap distance	mm	30~35 adjustable
9	Monitor	Type		JCQ-CⅠ
		Current measurement range	mA	0~5
		Operation current range	A	50~20000

Reference:

1/ Shendian resistor is widely used in China EHV (Extra hight voltage) projects of State Grid, Southern Power Grid.

2/ Supplied resistor to ABB/Siemens/Schneider more than 20 years, as well as other capacitor/switchgear manufacturers.

3/ Shendian resistor has been exported to more than 30 counties all over the world.
