Class 1 Switch Type Power Surge Protective Device SDZ100-50

Ask Lasest Price
Brand Name :	Xi'an Shendian
Model Number :	SDZ-100-50
Certification :	IEC 61643-311
Price :	To be determined by type and quantity.
Payment Terms :	T/T; L/C.
Delivery Time :	Ex-work 3 days~ 1 week depends on quantity.

Add to Cart

Product Details
Company Profile

Class 1 Switch Type Power Surge Protective Device SDZ100-50

Power Supply Surge Protective Device

Product introduction:

SDZ100-50 is class 1 switch-type surge protection. It can effectively release the incoming and inductive lightning on the low-voltage line of system, and effectively protect power supply equipment from lightning strike.

Characteristic:

1/ Impulse current reaches 10/350μs 60kA;

2/ Low voltage limitation;

3/ Nominal discharge current reaches 8/20μs 200kA;

4/ Strong capability to cut off residual current;

5/ Discharge monitor is applicable to configurate with RS485 communication.

Installation:

1/ Install on 35mm rail;

2/ It is necessary to series connect a fuse or air switch with SPD.

Maintenance:

SPD should be inspectied and maintenance in reuglar basis, pls duly replace SPD if it is red color in display window.

Standard Technical Data:

A: Class Ⅰ

Class	Ⅰ
Type	SDZ100-50/420	SDZ100-50/440
Max. continuous operation voltage (Uc)	420V	440V
Protection voltage Up	＜2.5kV	＜2.5kV
Power Supply	3 phase/ Wind power system	3 phase/ Wind power system
Nominal discharge current, In (8/20μs)	200kA/phase	200kA/phase
Impulse discharge current, limp (10/350μs)	60kA/phase	60kA/phase
Cross section of connection wire	16mm2~30mm2 (Mul.)	16mm2~30mm2 (Mul.)
Protection mode	L-PE; L-N; N-PE	L-PE; L-N; N-PE
Environment condition	-40℃~+85℃	-40℃~+85℃
Dimension (mm)	15035(n)78 (n is quanity)	15035(n)78 (n is quanity)
Installation	35mm std. rail	35mm std. rail
